NetWay81GP

PoE Midspan, 8 Port, 10/100/1000, 60W max per port (480W total power), Battery Charging, 115/230VAC Input

Altronix NetWay81GP is an 8-port midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE (up to 60W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup.

Specifications

  • Input
    • 115VAC, 60Hz, 5.5A or 230VAC, 50H/60z, 3.0A.
  • Power
    • Unit provides PoE / PoE+ / Hi PoE.
    • 60W full power per port.
    • Total power: 480W.
  • Ethernet
    • Connectivity: RJ45, auto-crossover
    • Wire type: 4-pair CAT5e or better structured cable
    • Distance: up to 100m
    • Speed: 10/100/1000 BaseT, half/full duplex, auto negotiation
  • Indicators (LED)
      • Yellow and Green LED (by RJ45 jack)
        • IP Link status, 10/100/1000 Base-T/active
      • Green LED
        • Port status
  • Battery Charging
    • Built-in battery charger (optional rack mount battery enclosure - RE2).
    • Automatic switchover to stand-by battery when AC fails.
    • (Batteries are sold separately).
  • Temperature
    • Operating: - 20ºC to 50ºC ( - 4ºF to 122ºF).
    • Storage: - 20º to 70ºC ( - 4ºF to 158ºF).
    • Relative Humidity: 85% +/- 5%.
    • BTU/Hr. (approx.): 500 BTU/Hr.
  • Operating Altitude
    • Up to 2,000m.

Agency Listings


CE Compliant

Accessories

Name Description
NetWayXT Ethernet Extender, 1 Port, 10/100, Passes PoE, Extends Data additional 100m
NetWayXTX Ethernet Extender, 1 Port, 10/100, Passes PoE/PoE+, Extends Data additional 100m
RE2 Rack Mount Battery Enclosure, 2U

Dimensions & Weight

Enclosure:
  • Modular 1U standard EIA 19" rack mount chassis.
  • Dimensions 19.12"W x 1.62"H x 8.5"D (486 mm W x 42 mm H x 216 mm D).
Weights (approximate):
  • Product Weigtht: 6.17 Lbs. (2.8 kg).
  • Shipping Weigtht: 7.5 Lbs. (3.4 kg).
