AL1024XB2V

Power Supply Charger, Single Fused Output, 24VDC @ 10A, 220VAC, Board

AL1024XB2V is a power supply/charger that converts a nominal 220VAC (working range 198VAC-256VAC), 50/60Hz input into a single 24VDC output.

  • Input
    • Nominal 220VAC (working range 198VAC-256VAC), 50/60Hz, 2.5A.
    • Input fuse rated @ 3.5A/250V.
  • Output
    • 24VDC output.
    • 10A of continuous supply current for Access Control applications.
    • 8A of continuous supply current for Fire Alarm applications.
    • Filtered and electronically regulated output.
    • Short circuit and thermal overload protection.
  • Battery Backup
    • Built-in charger for sealed lead acid or gel type batteries.
    • Automatic switch over to stand-by battery when AC fails.
    • Zero voltage drop when switched over to battery backup.
    • (Batteries are sold separately).
  • Supervision
    • AC fail supervision (form "C" contacts).
    • Notification trigger is selectable for 30 seconds (factory set) or 6 hours.
    • Low battery supervision (form "C" contacts).
    • Battery presence supervision (form "C" contacts).
  • Visual Indicators
    • AC input and DC output LED indicators.
  • Electrical
      • Temperature:
        • Operating: 0° C to 49° C (32° F to 120° F).
        • Storage: - 20° C to 70° C ( - 4° F to 158° F).
    • Relative Humidity 85% +/- 5%.
    • BTU/Hr (approx.): 123 BTU/Hr.
    • System AC input VA requirement: 550VA.
Dimensions (approximate):
  • 4.5"W x 8.4"L x 1.4"H (114.4 mm W x 213.4 mm L x 35.6 mm H).
Weights (approximate):
  • Product Weight: 1.15 Lbs. (0.52 kg).
  • Shipping Weight: 1.45 Lbs. (0.66 kg).
