T1618300

Open Frame Transformer, 16/18VAC @ 300VA, 115VAC

Altronix T1618300 open frame transformer provides power for electronic power supplies and equipment including security, access control, and surveillance devices.

Input
- 115VAC 50/60 Hz, 2.7A.
Output
- 16VAC/300VA (18.7A) or 18VAC/300VA (16.7A) supply current.
Temperature
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
- BTU/Hr (approx.): 154 BTU/Hr.

UL Recognized
