Page 4 - NetWay Spectrum Brochure
P. 4

Hardened PoE Switches with Power Supply/Chargers
            3-Port Hardened PoE Switches with Single SFP Port
         and Optimized Lithium Iron Phosphate Battery Charging

                                                10/100   10/100/1000                    Input:  Built-in   Enclosure
                                         SFP
       Model              Configuration         Ethernet   Ethernet      PoE ports      115/    Battery   Accommodates
                                        port(s)
                                                 ports      ports                      230VAC   Charger    Batteries
                                                                        3-Ports rated
                                                                         up to 30W
       NetWaySP3LWPX                      1      ---------    3         or 1-Port rated   3     LiFePO4       3
                                                                         up to 60W
                                                                       (75W total power)

                                                                        4-Ports rated
                                                                         up to 30W
       NetWay4ELWPX                       1       4         ---------   or 1-Port rated  3      LiFePO4       3
                                                                         up to 60W
                             Large                                     (75W total power)
                        Outdoor Enclosure
                         NEMA 4/4X, IP66                                4-Ports rated
                                                                         up to 30W
       NetWaySP4LWPX                      2      ---------    4         or 1-Port rated   3     LiFePO4       3
                                                                         up to 60W
                                                                       (75W total power)

                                                                        8-Ports rated
                                                                         up to 30W
       NetWaySP8LWPX                      2       6           2         or 1-Port rated  3      LiFePO4       3
                                                                         up to 60W
                                                                       (75W total power)
       Units supporting 802.3bt PoE ....


       NetWay4EBTWPX                      1
                             Large                                      4-Ports rated           LiFePO4,
                        Outdoor Enclosure        --------     4          up to 90W       3       SLA,         3
                         NEMA 4/4X, IP66                              (180W total power)         or Gel
       NetWaySP4BTWPX                     2


                              ™         NetWay Spectrum PoE Switches feature embedded LINQ™ Network Management Technology
                                        which let’s you remotely monitor, control and report power/diagnostics from anywhere over
                                        the network.


      BTL125
      Altronix BTL125 rechargeable Lithium Iron Phosphate ( LiFePO4) Battery provides optimal backup

      for security, access, and surveillance applications.
      -  Use with Altronix NetWay Spectrum fiber optic equipment with Optimized Lithium Iron Phosphate Battery charging circuit.

      -  Smart technology - low power disconnect.
      -  10 years shelf life.
      -  Up to 5,000 duty cycles.
      -  Environmentally friendly.



      4                                                                                  Lifetime Warranty  |  Made in the U.S.A.
   1   2   3   4   5   6   7   8   9
