T1618300K

Open Frame Transformer Kit, 16/18VAC @ 300VA, 115VAC

Altronix T1618300K open frame transformer kit provides power for electronic power supplies and equipment including security, access control, and surveillance devices. It includes T1618300 transformer and mounting hardware for TKH2 backplane.

Input
- 115VAC 50/60 Hz, 2.7A.
Output
- 16VAC/300VA (18.7A) or 18VAC/300VA (16.7A) supply current.
Temperature
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
- BTU/Hr (approx.): 154 BTU/Hr.

UL Recognized

Components of this kit are UL Listed sub-assemblies. Please refer to the corresponding Sub-Assembly Installation Guides for further information. Sub-assembly components of this kit can be found under the "Kit Contents" tab.
