FIRE  ACCESS   SECURITY


                             ENHANCED POWER SUPPLY/CHARGERS


        eFlow102NB                                eFlow104NB
        • UL Listed Sub-Assembly in the U .S . and Canada for Access Control .  • UL Listed Sub-Assembly in the U .S . and Canada for Access Control
        • Two (2) 12VDC power outputs               and Burglar . UL Listed Sub-Assembly in the U .S . for Fire .
          - Switched main (affected by fire alarm)   • Two (2) 24VDC power outputs
          - Unswitched aux . (continuous power)     - Switched main (affected by fire alarm)
        • 10 amp total supply current .             - Unswitched aux . (continuous power)
        Board dimensions: 4 .63”L x 7 .625”W x 1 .875”H  • 10 amp total supply current .
                                                  Board dimensions: 4 .63”L x 8 .25”W x 1 .6”H

         Features:                                                                          21
         •  120VAC 60Hz . input .
         •  Additional aux . power-limited output rated @ 1 amp (unswitched) .
         •  Over voltage protection .
         •  Supervised Fire Alarm disconnect (latching or non-latching) .
         •  Low power cutoff - protects stand-by batteries from deep discharge .
         •  Built-in charger for sealed lead acid or gel type batteries .
         •  Zero voltage drop upon transfer to battery backup .
         •  Automatic switch over to stand-by battery when AC fails .
         •  AC fail, low battery and battery presence supervision .
        * Above models available mounted in enclosure - refer to pgs. 66-69 for further info.  EFLOW102NB

         Monitor and control eFlow Series Power Supply/Chargers with LINQ2 - Network Communication Modules (pg. 34)
